Four-Row Cylindrical Roller Bearing
Four-row cylindrical roller bearings for rolling mill work rolls and backup rolls — maximum radial load capacity for hot strip mills, plate mills, and section mills. Factory direct from ANDE bearing manufacturer.
Technical Overview
Four-Row Cylindrical Roller Bearings are designed for the most demanding heavy-load applications in steel rolling mills. The four-row configuration distributes extremely high radial loads across four rows of cylindrical rollers, providing the maximum radial load capacity in a compact design. These bearings are primarily used in the bearing chock assemblies of work rolls and backup rolls in hot strip mills, plate mills, and section mills. ANDE four-row cylindrical roller bearings are manufactured from premium bearing steel with precision-machined raceways and robust brass or steel cage designs for reliable operation under the extreme conditions of continuous steel rolling. We provide interchangeable size and performance benchmarking solutions that can directly replace equivalent four-row cylindrical roller bearings from major international manufacturers. All trademarks mentioned belong to their respective owners.
Key Features
- Four-row design for maximum radial load capacity
- Compact cross-section for space-constrained roll chock assemblies
- Precision-machined raceways for uniform load distribution
- Robust cage designs (machined brass / pin-type steel) for high-speed and heavy-load operation
- Available with tapered bore for easy mounting on roll necks
- Interchangeable dimensions with SKF, Timken, NSK, and other major brand equivalents
- Multiple clearance options (CN, C3, C4) for different operating temperatures
- Available with custom lubrication grooves and sealing configurations
Technical Specifications
| Property | Value |
|---|---|
| Type | Four-Row Cylindrical Roller Bearing |
| Bore Diameter | 100 mm - 900 mm |
| Outer Diameter | 150 mm - 1280 mm |
| Width | 140 mm - 860 mm |
| Material | High-carbon chrome bearing steel / Carburized steel |
| Cage Type | Machined brass / Pin-type steel cage |
| Precision Class | Normal / P6 available |
| Speed Rating | Up to 800 RPM (size dependent) |
| Dynamic Load Rating | 800 kN - 12,000 kN |
| Static Load Rating | 1,200 kN - 18,000 kN |
| Seal Options | Open / Custom sealing configurations available |
| Standards | ISO 15:2017, manufacturer standard |
